| MODEL | Pounds / 24 Hours | Kilograms / 24 Hours | U.S Tons / 24 Hours | Hundredweight / 24 Hours |
|---|---|---|---|---|
| AV020C | 2,000 | 907 | 1 | 9 |
| AV020CR | 2,000 | 907 | 1 | 9 |
| AV040C | 4,000 | 1,814 | 2 | 12 |
| AV040CR | 4,000 | 1,814 | 2 | 12 |
| AV060C | 6,000 | 2,722 | 3 | 27 |
| AV060CR | 6,000 | 2,722 | 3 | 27 |
| AV080C | 8,000 | 3,629 | 4 | 36 |
| AV080CR | 8,000 | 3,629 | 4 | 36 |
| AV100C | 10,000 | 4,536 | 5 | 45 |
| AV100CR | 10,000 | 4,536 | 5 | 45 |
| AV120C | 12,000 | 5,443 | 6 | 54 |
| AV120CR | 12,000 | 5,443 | 6 | 54 |
| AV200C | 20,000 | 9,072 | 10 | 91 |
| AV200CR | 20,000 | 9,072 | 10 | 91 |
| AV400C | 40,000 | 18,144 | 20 | 181 |
| AV400CR | 40,000 | 18,144 | 20 | 181 |
| AV400W | 40,000 | 18,144 | 20 | 181 |
| MODEL | SELF-CONTAINED Air Cooled condensing unit in the same base than the evaporator (Complete machine in one piece) | REMOTE Air Cooled condensing unit in different base than the evaporator (Machine separated in two pieces) | WATER COOLED Water Cooled condensing unit with cooling tower and recirculating water pump |
|---|---|---|---|
| AV020C | |||
| AV020CR | |||
| AV040C | |||
| AV040CR | |||
| AV060C | |||
| AV060CR | |||
| AV080C | |||
| AV080CR | |||
| AV100C | |||
| AV100CR | |||
| AV120C | |||
| AV120CR | |||
| AV200C | |||
| AV200CR | |||
| AV400C | |||
| AV400CR | |||
| AV400W |
| MODEL | POWER CONSUMPTION KW/H | WATER USAGE Gallons/24 horas |
|---|---|---|
| AV020C | 3.5 | 260 |
| AV020CR | 3.5 | 260 |
| AV040C | 6 | 520 |
| AV040CR | 6 | 520 |
| AV060C | 7 | 780 |
| AV060CR | 7 | 780 |
| AV080C | 8 | 1040 |
| AV080CR | 8 | 1040 |
| AV100C | 15 | 1300 |
| AV100CR | 15 | 1300 |
| AV120C | 16 | 1550 |
| AV120CR | 16 | 1550 |
| AV200C | 32 | 2600 |
| AV200CR | 32 | 2600 |
| AV400C | 88 | 5180 |
| AV400CR | 88 | 5180 |
| AV400W | 70 | 5180 |
